Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW

Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Garantie: Aangepast
Type: Stil (super Stil) of Open, Stil, enz., in-line/6-Cylinder/4-Stroke/4-Valve/19L, Geluiddichte (Stille
Configuratiescherm: LCD Digitale Vertoning, Diepzee, ComAp, Diepzee/ComAp/Harsen/Smartgen 6110, Smartgen
Uitvoertype: AC Enig/In drie stadia
Controleur: Diepzee/Smartgen/enz.
Sollicitatie: Indurstybank enz.
Nominale spanning: 400/230V, 110-480V, 220V/380V, 110V/240V, 380V
Dynamo: Marathon, Stamford, SLG/Stamford/Marathon/Meccatle/Leroy-somer, Stamford of Newtec, Engga
Productnaam: Dieselgenerator, generator 1875KVA, aangedreven door YUCHAI-dieselgenerator, standby-gebruiksvermoge
kleur: De eis van klanten
Frequentie: 50/60 Hz
Nominaal vermogen: 1500 kW
MOTOR: Originele Baudouin
Koelmethode: Waterkoelingssysteem
Markeren:

Baudouin diesel generator 1500kW

,

silent diesel power generator

,

open type electric generator
Basis informatie
Plaats van herkomst: China
Merknaam: BAUDOUIN
Certificering: CE
Modelnummer: 16M33G2000/5
Betalen & Verzenden Algemene voorwaarden
Verpakking Details: Multiplex
Levertijd: 30 dagen
Levering vermogen: 500 stks per maand
Productomschrijving
Intelligent Diesel Generator 1500kW 1875KVA Open Type Silent Diesel Electric Power Generator
Product Overview

Our 1500kW 1875KVA BOBIG BAUDOUIN diesel generator (Model: 16M33G2000/5) is designed to provide reliable power for a wide range of applications. Backed by the renowned BAUDOUIN brand, it offers high-quality performance and long-term durability.

Key Features
Power Performance

Rated Power: 1500kW (1875KVA) for various industrial, commercial, and residential applications. The prime power output is stable and efficient, ensuring continuous operation even under heavy loads. Frequency: Standard 50Hz operation suitable for most electrical equipment.

Engine Excellence

Powered by the 16M33G2000/5 BAUDOUIN engine, combining advanced technology and high-quality manufacturing. Known for high torque, fuel efficiency, and low emissions. Engine Speed: 1500 RPM for smooth, consistent power supply with minimal wear.

Technical Specifications
General Information Prime Power Standby Power
Rated Power (kVA) 1875 2063
Power Rating (kW) 1500 1650
Frequency (Hz) 50
Engine Model 16M33G2000/5
Engine Speed (RPM) 1500
Phase 3
PF 0.8
Control System Digital
Rated Voltage (V) 400/230 (According to customer requirements)
Fuel Tank Capacity: ≥ 8h @ 75% load
PRP: Prime power available for unlimited annual hours in variable load applications (GB/T2820-97). 10% overload capability available for 1 hour within 12-hour operation.
ESP: Standby power rating for emergency power during utility interruptions. No overload, utility parallel or negotiated outage operation capability.
Engine Specifications
Engine Model & Manufacturer 16M33G2000/5 (BAUDOUIN)
Number of Cylinders / Valves 16 / 64
Cylinders Arrangement Vee
Bore x Stroke (mm) 150 x 185
Displacement (L) 52.3
Thermodynamic Cycle Diesel 4 stroke
Mean Piston Speed (m/s) 9.25
BMEP @ ESP (Bar) 27.53
Cooling System Liquid (water + 50% antifreeze)
Injection System Direct
Fuel System High Pressure Common Rail
Aspiration Turbocharged and Aftercooled
Compression Ratio 15:1
Flywheel Housing SAE 0
Flywheel 18"
Number of Teeth on Flywheel Ring Gear 194
Inertia of Flywheel (kg•m²) 7.2
Inertia of Crankshaft (kg•m²) 10.1
Emission Standard N/A
Overall Dimensions with Radiator (L x W x H) (mm) 3967 x 2237 x 2485
Engine Dry Weight without Radiator (kg) 5200
Engine Dry Weight with Radiator (kg) 6450
Engine Wet Weight with Radiator (kg) 7151
Alternator Specifications
Alternator Brand BOBIG
Alternator Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-454C
Alternator Rated Power 1500kW/1875kVA
Rated Voltage (V) 230V/400V
Rated Frequency 50Hz
Connecting Type 3 Phase and 4 W
Number of Bearing 1
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class H class
Telephone Influence Factor (TIF) ≤50
THF ≤2%
Voltage Regulation, Steady State ≤±1%
Transient State Voltage ≤-15%~+20%
Dimensions and Weight
Model BBDA2063 (Open Type) BBDA2063S (Silent Type)
Length (L) mm 5200 **
Width (W) mm 2250 **
Height (H) mm 2550 **
Tank Capacity (L) 3450 **
Applications
  • Industrial Use: Backup power source for factories to ensure continuous production during outages
  • Commercial Buildings: Office buildings, shopping malls, and hotels for essential services
  • Residential Areas: Reliable power for communities with unstable power grids
Warranty and Service

BOBIG products include a one-year or 1000-hour warranty (whichever comes first). During warranty, we provide free replacement of parts damaged due to production or material quality. After expiration, we offer cost-effective spare parts and maintenance services.

Why Choose Us
  • Brand Reputation: BAUDOUIN is a trusted brand with a long history of quality products
  • Quality Assurance: Manufactured to international standards with rigorous quality inspections
  • Customization Options: Tailored solutions based on specific customer requirements
Company Information

We are an electrical machinery manufacturer specializing in technological research, production, and sales. With a 10,000 square meter factory area including 1,000sqm standard construction, 160 employees (20 technicians), and products including gasoline generators, diesel generators (5-2000kVA), gas generators, and pumps.

Factory & Facilities
Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 0 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 1 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 2 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 3 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 4 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 5 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 6 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 7 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 8 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 9 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 10 Intelligent diesel Generator 1500kW 1875KVA Open Type Silent diesel Electric Power Make Generator 1500kW 11
Frequently Asked Questions
What is your MOQ, payment method, delivery time?

MOQ: 1 set. Payment: 30% T/T deposit, 70% balance before delivery, or 100% L/C, trade assurance, PayPal, Western Union. Delivery: 10-15 working days after deposit receipt.

Which port do you often use when exporting?

Fuzhou port, Fujian province or as customer request.

Is there any spare parts you can provide for maintenance?

We provide regular engine filters (air, water, fuel, oil) for customer self-maintenance.

Can you offer parts if we need them?

Yes, we can provide parts at any time (not limited to warranty period), typically shipped within 3-5 days.

Can voltage, frequency, tank capacity, phase and color be customized?

Yes, all specifications can be customized according to your requirements.

What is your distribution policy?

We welcome distributors worldwide and can issue authority certificates and sign agreements accordingly.
