Baudouin 320kw 400kw Water Cooling Alternator Electric Generator

1
MOQ
Baudouin 320kw 400kw Water Cooling Alternator Electric Generator
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Vermogen: 320 kW
Nominaal vermogen: 400kva
Controlesysteem: Digitaal
Tankinhoud: 736L
Fase: 3
Frequentie: 50/60 Hz
Type: Stil/open
Markeren:

Baudouin water cooling alternator generator

,

Baudouin 320kw diesel generator

,

400kw electric generator with warranty
Basis informatie
Plaats van herkomst: China
Merknaam: BAUDOUIN
Modelnummer: 6M21G400/5
Betalen & Verzenden Algemene voorwaarden
Verpakking Details: 285 cm * 110 cm * 172,5 cm
Levertijd: 5-8 werkdagen
Betalingscondities: L/C, T/T
Productomschrijving
Baudouin 320kw 400kw Water Cooling Alternator Electric Generator
Baudouin 320KW 400kva Digital Panel Super Silent Diesel Genset - Model 6M21G400/5. A dependable power generator for industrial and commercial environments. We offer various power configurations that can be customized according to your needs.
Please feel free to contact us!
Baudouin 320kw 400kw Water Cooling Alternator Electric Generator 0
Technical Specifications
General information Prime power Standby power
Rated Power (kVA) 400 440
Power Rating (kW) 320 352
Frequency (Hz) 50
Engine Model 6M21G400/5
Engine Speed (RPM) 1500
Phase 3
PF 0.8
Control System Digital
Rated voltage (V) 400/230
(According to customer requirements)
Fuel tank capacity operating time ≥ 8h @ 75% load
PRP ● Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour of operation
ESP ● The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating
Baudouin 320kw 400kw Water Cooling Alternator Electric Generator 1
Dimensions and Weight
Dimension and Weight BBDA440 BBDA440S
Model BBDA440 BBDA440S
Type Open type Silent type
Length (L) mm 2850 4300
Width (W) mm 1100 1600
Height (H) mm 1725 2250
Tank capacity (L) 736 736
Engine Specifications
Engine model & manufacturer 6M21G400/5(BAUDOUIN)
Engine model 6M21G400/5
N° of Cylinders / Valves 6/24
Cylinders arrangement In line
Bore x Stroke (mm) 127 x 165
Displacement (L) 12.54
Thermodynamic Cycle Diesel 4 stroke
Firing Order 1-5-3-6-2-4
Mean Piston Speed (m/s) 8.25
BMEP @ ESP (Bar) 24.56
Cooling System Liquid (water + 50% antifreeze)
Injection System Direct
Fuel System Mechanical Pump
Aspiration Turbocharged and Aftercooled
Compression ratio 16:1
Flywheel housing SAE 1
Flywheel 14"
Rotation Viewed from Flywheel Counter Clockwise
Allowed static bending moment of the flywheel housing 11700
N° of teeth on flywheel ring gear 136
Inertia of flywheel (kg•m²) 2.32
Inertia of crankshaft (kg•m²) 0.574
Emission standard N/A
Overall Dimensions with radiator (Length x Width x Height) (mm) 2011 x 1096 x 1363
Engine dry weight without radiator and without radiator pipes (kg) 1000
Engine dry weight with radiator and radiator pipes (kg) 1150
Engine wet weight with radiator (includes oil, coolant) (kg) 1233
Alternator Specifications
Alternator Brand BOBIG
Alternator Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-314ES
Alternator Rated Power 320kw/400kva
Rated voltage (V) 230v/400v
Rated frequency 50hz
Connecting Type 3 Phase and 4 W
Number of Bearing 1
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper
Insulation Class H class
Telephone Influence Factor (TIF) ≤50
THF ≤2%
Voltage Regulation, Steady State ≤±1%
Transient State Voltage ≤-15%～+20%
Company Profile
Established in 2004, Fujian Bobig Electric Machinery Co., Ltd. is an electrical machinery manufacturer specializing in technological research, production and sales. With a total factory area of 10,000 square meters, including 1,000sqm standard construction area, we have 160 employees, including 20 technicians.
Our main products include air-cooled gasoline generators, air-cooled diesel generators, air-cooled welding & generating sets and water-cooled diesel generator sets. Our small air-cooled brushless generators and welding & generating sets have earned a great reputation in the market for their reliable quality.
We adhere to the principle of "Quality, Creation, Service and Development", continuously updating technology, improving quality and providing better service. Our advanced testing equipment includes CAD system, auto assembling & winding & inserting equipment, vacuum dipping system and digital testing equipment.
We maintain strict quality control and have obtained ISO9000 Quality System Certification. We welcome you to build sincere cooperation with us.
Baudouin 320kw 400kw Water Cooling Alternator Electric Generator 2 Baudouin 320kw 400kw Water Cooling Alternator Electric Generator 3
After Sales Services
As a leading Chinese diesel generator manufacturer, we offer comprehensive export services to meet global market needs:
  • Customized manufacturing
  • Quality control
  • International logistics
  • Documentation and certification
  • Trade support
  • After-sales service
  • Customer training
  • Market support
  • Technical collaboration
We deliver tailored diesel generator solutions that meet international quality standards. Our experienced team handles all logistics to ensure timely delivery. We provide necessary documentation compliant with international trade requirements and offer after-sales support including technical assistance and spare parts supply.
Frequently Asked Questions
Q: Are you a manufacturer or a trading company?
A: We are a professional manufacturer with our own factory located in Fujian, China. We welcome you to visit our facility and production line to see our quality control processes firsthand.
Q: What is the minimum order quantity (MOQ)?
A: Our standard MOQ is 1 set. We are flexible and can discuss volume orders for larger projects to provide better pricing.
Q: What is the delivery time after order confirmation?
A: Production time varies by quantity and inventory status. Typically 20-30 days for standard models. We'll provide a precise timeline upon order confirmation.
Q: What payment terms do you offer?
A: We commonly accept T/T with 50% deposit and 50% balance before shipment. For established relationships, we can discuss other terms like L/C.
Q: Do you perform factory inspection before shipment?
A: Absolutely. Every unit undergoes thorough testing in our factory before shipment.
